| Type of Product | Temperature Sensor Low Cost Type |
| Model No | E52-IC1DY-M8-1M |
| Series | E52 Series |
| Type | Screw-Type Lead Wire Direct Outlet |
Type of Product |
Temperature Sensor Low Cost Type |
Model No |
E52-IC1DY-M8-1M |
Series |
E52 Series |
Type |
Screw-Type Lead Wire Direct Outlet |
Material |
(Protective tube) SUS304 |
Monotaro ID |
46672841 |
Terminal Shape |
Direct lead wire type/Y type crimp terminal |
Temperature Range (℃) |
0 to 350 (in dry air) |
Lead Wire |
Fully glass wool covered outer shield (finished outer dimensions 3.1 x 2.0), 1/0.65, 0 to 180°C |
Wire Type |
J |
Method |
Non-ground type |
JIS Class |
2 (0.75 class) |
Wire Diameter (mm) |
0.65 (single wire) |
Country of Origin |
Japan |
Import Country |
Direct Import from Japan |
Name of Manufacturer/Packer/Importer |
Omron Corporation |
Lead Wire Length |
1 m |
Protective Tube Length L (mm) |
Thread pitch M8 |
Dimension B (Φmm) |
15 |
Dimension A (Φmm) |
5.3 |
Dimension C |
13 mm |
