| Type of Product | Temperature Sensor |
| Model No | E52-P15AY D=3.2 8M |
| Type | Sheath platinum resistance thermometer |
| Material | (Sheath) SUS316 |
Warranty as per brand
100% Original Products
Secure payments
100% Buyer protection
Top Brands
Type of Product |
Temperature Sensor |
Model No |
E52-P15AY D=3.2 8M |
Type |
Sheath platinum resistance thermometer |
Material |
(Sheath) SUS316 |
Temperature Range |
-196 to +450 (in dry air) |
Monotaro ID |
46782574 |
Terminal Shape |
Y-type crimp terminal for M3.5 |
Protective Tube Length L (cm) |
15 cm |
Lead Wire |
General use, all vinyl coating (-20 to + 70 ° C, 12 / 0.18, 0.3SQ, finished outer diameter approx. Φ4.8, sleeve part 0 to + 70 ° C) |
Wire Type |
Pt100 |
Method |
3 conductor type |
JIS Class |
B (B class) |
Lead Wire Length (mm) |
8 m |
Protective Tube Diameter D (Φmm) |
Φ3.2 mm |
Sheath outer diameter (Φmm) |
Φ3.2 mm |
Country of Origin |
JAPAN |
Name of Manufacturer/Packer/Importer |
Omron Corporation |
