| Type of Product | Temperature and Humidty Sensor |
| Model No | QFA3160D |
| Weight | 0.152 Kg |
| Operating Temperature | -40 to +70 °C |
Type of Product |
Temperature and Humidty Sensor |
Model No |
QFA3160D |
Weight |
0.152 Kg |
Operating Temperature |
-40 to +70 °C |
Accuracy |
at AC/DC 24 V in 23 °C -/+0.3 K; 15 to 35 °C -/+0.6 K; -35 to +70 °C -/+0.8 K; Accuracy 1 - at 23 °C and AC/DC 24 V in 0 to100 % r.h. ; -/+2 % r. h. |
Dimension |
144 X 62.8 X 39 mm |
Temperature Range |
0 to 50 °C / – 40 to +70 °C/ -35 to +35 °C |
Operating Voltage |
AC 24 V, DC 13.5 to 35 V |
Operating Humidity |
0 to 100 % RH, (with condensation) |
Country of Origin |
India |
Name of Manufacturer/Packer/Importer |
INSTRUKART HOLDING |
Measuring Parameter |
relative humidity and temperature |
Humidity Range |
0 to 100% RH |
Supply Scope |
1 unit of Siemens QFA3160D and Instruction Manual |
Sensing Element |
Pt 1000 |
