| Type | 16-Point Input Terminal |
| Model No | GX-ID1622 |
| Type of Product | Digital I/O Terminal, Screw-Type 3-Tier Terminal Block |
| Voltage | ON Voltage: DC15 V or more (Between Each Input Terminal and G) OFF Voltage: DC 5 V or less (Between Each Input Terminal and G) |
Type |
16-Point Input Terminal |
Model No |
GX-ID1622 |
Type of Product |
Digital I/O Terminal, Screw-Type 3-Tier Terminal Block |
Voltage |
ON Voltage: DC15 V or more (Between Each Input Terminal and G) OFF Voltage: DC 5 V or less (Between Each Input Terminal and G) |
Withstand Voltage |
AC 600 (Between Isolated Circuits) |
Monotaro ID |
39071864 |
Country of Origin |
China |
Import Country |
Direct Import from Japan |
Type of Sign |
Din 35 mm Rail Mounting |
Storage Temperature |
-25 to 65 °C |
Name of Manufacturer/Packer/Importer |
Omron Corporation |
Mass (g) |
370 or Less |
Current Consumption (mA) |
Unit Power Supply: 90 or Less (At Power Supply Voltage 20.4 To 26.4 Vdc) I/O Power Supply: 5 or Less (At Power Supply Voltage 20.4 To 26.4 Vdc) |
Case Material |
Case (Including Metal Parts At Both Ends): Aluminum, Zinc Die-Cast |
Cap Material |
ABS Resin |
Power Supply Voltage (V) |
Unit Power Supply: DC 20.4 To 26.4 (DC 24 V-15 To +10%) I/O Power Supply: DC 20.4 To 26.4 (DC 24 V-15 To +10%) |
Applicable Standard |
cULus (Class I Div 2 Hazardous Location Certified Product), NK, Lloyd, EC Directive |
