| Model No | XW2Z-500F |
| Type of Product | Connector Terminal Block Conversion Unit |
| Rated Current (A) | 1 |
| Rated Voltage (V) | AC 125, DC 24 |
Model No |
XW2Z-500F |
Type of Product |
Connector Terminal Block Conversion Unit |
Rated Current (A) |
1 |
Rated Voltage (V) |
AC 125, DC 24 |
Monotaro ID |
46594326 |
Country of Origin |
JAPAN |
Import Country |
Direct Import from Japan |
Compatible Models |
MIL connector 20 poles - Cable with loose wire crimp terminal 20 poles |
Name of Manufacturer/Packer/Importer |
Omron Corporation |
Operation Ambient Temperature (°C) |
0 to +80 |
Insulation Resistance (MOhm) |
100 or more (at 500 V DC) |
Withstand voltage (V / min) |
(Connector part) AC500. ( Leakage current 1 mA or less) |
Contact Resistance (ohm) |
(Connector part) 20 mΩ or less (20mV or less, 100mA or less) |
Cable Length (m) |
5 |
Cable |
UL2464 interface cable |
