| Model No | T-3025-L-W |
| Type of Product | Terminal Long Type |
| Insulation Resistance | DC500V, 100MΩ or more |
| Withstand Voltage | AC1000V (1 minute) |
Model No |
T-3025-L-W |
Type of Product |
Terminal Long Type |
Insulation Resistance |
DC500V, 100MΩ or more |
Withstand Voltage |
AC1000V (1 minute) |
RoHS Directive |
Correspondence |
Monotaro ID |
64428798 |
Country of Origin |
Japan |
Import Country |
Direct Import from Japan |
Pack of |
1 Pcs |
Rating |
125V-10A |
Name of Manufacturer/Packer/Importer |
Sato Parts Co., Ltd. |
Body Color |
White |
Insulator Material |
Nylon 6 |
Suitable Door Thickness to Mount (mm) |
7.0(MAX) |
Panel Mounting Method |
Nut tightening |
Nut |
[Tightening torque] 0.6N・m or less |
Nut Width Across Flats (mm) |
10 |
