| Model No | ML-7000-BR |
| Type of Product | Screwless Terminal Block, Connectable Type |
| RoHS Directive | Correspondence |
| Rated Voltage (V) | 300 |
Model No |
ML-7000-BR |
Type of Product |
Screwless Terminal Block, Connectable Type |
RoHS Directive |
Correspondence |
Rated Voltage (V) |
300 |
Monotaro ID |
8620753 |
No. of Pole |
1P |
Contact Resistance |
20 mΩ or less (initial value) |
Country of Origin |
Japan |
Import Country |
Direct Import from Japan |
Type of Sign |
Direct attachment |
Pack of |
1 Pcs |
Specifications |
Compatible with both stranded and single wires. It can be connected using the uneven part on the side of the body. Eight standard button colors are available for line identification. A single body supports a wide range of wire rods, so it can be used in various ways. Wire diameter range that requires button operation: Twisted wire 0.2mm <sup>2</sup> to 2.0mm <sup>2</sup> / single wire Φ0.4mm to Φ0.9mm |
Terminal Spacing |
9.2 mm |
Name of Manufacturer/Packer/Importer |
Sato Parts Co., Ltd. |
Body Color |
GY (gray) |
Applicable Standard |
UL standard (field wiring compatible), C-UL standard, TUV standard (IEC60947-7-1), PSE mark product (certified institution name JET) |
Insulator Material |
Body: Nylon 66 (UL94V-0) <br> Button: PPE (UL94V-0) |
Withstand voltage (V / min) |
AC2000 |
Terminal Connection Type |
Screwless |
Insulation_Resistance (MΩ) |
100 or more (DC500V) |
Current Rating, IEC (A) |
10 |
Current Rating, UL (A) |
10 |
Rating of Suitable Cable |
Single line: Φ1.2mm (AWG16), twisted wire: 1.25mm <sup>2</sup> (AWG16), wire diameter Φ0.18mm more |
Standard Cable Stripping Length (mm) |
10 |
Recommended Tool |
Slotted screwdriver (shaft diameter Φ6mm, cutting edge width 6mm) * Anything that can push the button is acceptable |
Suitable Cable Range |
Single wire: Φ0.4mm to Φ1.6mm (AWG26 to AWG14), twisted wire: 0.2mm <sup>2</sup> to 2.0mm <sup>2</sup> (AWG24 to AWG14), strand diameter Φ0.18mm or more * Single wire Φ1.2mm when used with PSE Please use Φ1.6mm. |
Color of Operating Part |
BR (brown) |
