| Model No | SL-6000-V-BL |
| Type of Product | Screwless Terminal Block SL-6000-V |
| Rated Current (A) | 10 |
| Rated Voltage (V) | 300 |
Model No |
SL-6000-V-BL |
Type of Product |
Screwless Terminal Block SL-6000-V |
Rated Current (A) |
10 |
Rated Voltage (V) |
300 |
Monotaro ID |
11095638 |
No. of Pole |
1 Pole |
Country of Origin |
Japan |
Import Country |
Direct Import from Japan |
Type of Sign |
Printed board |
Pack of |
1 Pcs |
Terminal Spacing |
5.08 mm |
Name of Manufacturer/Packer/Importer |
Sato Parts Co., Ltd. |
Insulator Material |
Body: Nylon 66 (UL94V-0), Button: PPE (UL94V-0) |
Terminal Connection Type |
Screwless |
Rating of Suitable Cable |
Single line: Φ1.2mm (AWG16), twisted wire: 1.25mm² (AWG16), wire diameter Φ0.18mm more |
Standard Cable Stripping Length (mm) |
9 to 10 |
Recommended Tool |
Slotted screwdriver (shaft diameter Φ3mm, cutting edge width 2.6mm) * Anything that can push the button is acceptable |
Suitable Cable Range |
Single wire: Φ0.4mm to Φ1.2mm (AWG16 to AWG26), twisted wire: 0.2mm² to 1.25mm² (AWG16 to AWG24), strand diameter Φ0.18mm or more, ferrule: 0.25mm² to 0.5mm² (AWG20 ~ AWG24) |
Color of Operating Part |
BL (blue) |
suitable crimping terminal |
PC terminal |
