| Model No | SL-4000-AWJH-8PGY |
| Type of Product | Screwless Terminal Block |
| Material | Main insulation (receptacle body) / Nylon 66 (UL94V-0) |
| RoHS Directive | Correspondence |
Model No |
SL-4000-AWJH-8PGY |
Type of Product |
Screwless Terminal Block |
Material |
Main insulation (receptacle body) / Nylon 66 (UL94V-0) |
RoHS Directive |
Correspondence |
Rated Voltage (V) |
300 |
Monotaro ID |
65814078 |
No. of Pole |
8 |
Country of Origin |
Japan |
Import Country |
Direct Import from Japan |
Type of Sign |
Printed board |
Pack of |
1 Pcs |
Specifications |
This item is only for the receptacle side of SL-4000-AWSH. It is approved as a C-UL product when used with a plug. |
Terminal Spacing |
3.81 mm |
Name of Manufacturer/Packer/Importer |
Sato Parts Co., Ltd. |
Body Color |
GY (gray) |
Applicable Standard |
UL standard, C-UL standard, TUV standard (IEC61984) |
Withstand voltage (V / min) |
AC2000 |
Terminal Connection Type |
Screwless |
Insulation_Resistance (MΩ) |
100 mΩ or more (DC500 V) |
Current Rating, IEC (A) |
5 |
Current Rating, UL (A) |
5 |
suitable crimping terminal |
PC terminal |
