Ships within 19 days
View
View
View
View
| Model No | ML-5300-M4-4P |
| Type of Product | Screw Type Terminal Block |
| Material | Main insulation / PBT (UL94V-0) |
| RoHS Directive | Correspondence |
Model No |
ML-5300-M4-4P |
Type of Product |
Screw Type Terminal Block |
Material |
Main insulation / PBT (UL94V-0) |
RoHS Directive |
Correspondence |
Rated Voltage (V) |
300 |
Monotaro ID |
65813536 |
No. of Pole |
4 Pole |
Terminal Screw |
M4x8 |
Country of Origin |
Japan |
Import Country |
Direct Import from Japan |
Type of Sign |
Direct attachment |
Pack of |
1 Pcs |
Terminal Spacing |
9.5 mm |
Name of Manufacturer/Packer/Importer |
Sato Parts Co., Ltd. |
Body Color |
B (black) |
Applicable Standard |
UL standard, TUV standard |
Withstand voltage (V / min) |
AC3000 |
Terminal Connection Type |
screw |
Insulation_Resistance (MΩ) |
1000 mΩ or More (DC500V) |
Current Rating, IEC (A) |
25 |
Current Rating, UL (A) |
25 |
Screw Tightening Torque (Nm) |
1.2MAX |
