| Model No | ML-3000-2P-W |
| Type of Product | Screwless Terminal Block |
| Insulation Resistance | DC500V, 100MΩ or more |
| Withstand Voltage | AC2000V (1 minute) |
Model No |
ML-3000-2P-W |
Type of Product |
Screwless Terminal Block |
Insulation Resistance |
DC500V, 100MΩ or more |
Withstand Voltage |
AC2000V (1 minute) |
RoHS Directive |
Correspondence |
Monotaro ID |
64428667 |
No. of Pole |
1 pole |
Contact Resistance |
[Initial value] 20 mΩ or less |
Country of Origin |
Japan |
Import Country |
Direct Import from Japan |
Pack of |
1 Pcs |
Rating |
300V-10A |
Name of Manufacturer/Packer/Importer |
Sato Parts Co., Ltd. |
Rating of Suitable Cable |
Solid wire: Φ1.2mm (AWG16), Stranded wire: <sup>1.25mm2</sup> (AWG16), Wire diameter Φ0.18mm or more |
Standard Cable Stripping Length (mm) |
11 |
Suitable Cable Range |
Solid wire: Φ0.4mm to Φ1.6mm (AWG26 to AWG14), Stranded wire: 0.3mm <sup>2</sup> to 1.25mm <sup>2</sup> (AWG22 to AWG16) Wire diameter Φ0.18mm or more |
Color of Operating Part |
White |
