| Model No | PCV5-2M202B |
| Type of Product | Spring Lock Type Connector Terminal Block (PCV5 Series) |
| Connector | Made by Honda Tsushin Kogyo Co., Ltd./MR-20RFD2(+) (female) |
| Dimensions A (mm) | 57 |
Model No |
PCV5-2M202B |
Type of Product |
Spring Lock Type Connector Terminal Block (PCV5 Series) |
Connector |
Made by Honda Tsushin Kogyo Co., Ltd./MR-20RFD2(+) (female) |
Dimensions A (mm) |
57 |
Monotaro ID |
87052314 |
No. of Pole |
20 Pole |
Dimensions B (mm) |
49 |
Country of Origin |
Japan |
Import Country |
Direct Import from Japan |
Type of Sign |
DIN Rail |
Rated Insulation Voltage (V) |
125 V AC/DC |
Terminal Spacing |
5 mm |
Name of Manufacturer/Packer/Importer |
Toyo Giken Co., Ltd. |
Operation Ambient Temperature (°C) |
-15 to +60°C (no freezing or freezing) |
Withstand voltage (V / min) |
AC600 |
Terminal Connection Type |
Screwless / Multipolar Female |
Insulation_Resistance (MΩ) |
100 or more (at 500 VDC) |
Current Rating, JIS (A) |
1 |
Suitable Sockets |
[Solder type] MR-20M (+), [Case] MR-20L |
