| Model No | C32D-CT1E |
| Type of Product | Output Terminal Block Type |
| Pole | 32 points assigned per station |
| Monotaro ID | 87056383 |
Model No |
C32D-CT1E |
Type of Product |
Output Terminal Block Type |
Pole |
32 points assigned per station |
Monotaro ID |
87056383 |
Connection Type |
External / 7-pole 2-piece connector (transmission path, unit power supply terminal, FG terminal) |
Country of Origin |
Japan |
Import Country |
Direct Import from Japan |
Common Specifications |
32 points per common |
Type of Sign |
DIN Rail |
Name of Manufacturer/Packer/Importer |
Toyo Giken Co., Ltd. |
Mass (g) |
About 205 |
Insulation Type |
Photocoupler insulation |
Withstand voltage (V / min) |
[Between DC external terminals and ground] AC500 |
Terminal Connection Type |
e-CON |
Current Rating, JIS (A) |
Approx.0.5 / 1 point (0.225 / 1 point when all points are ON) |
No. Of Output |
32 |
Response Time |
ON→OFF/1.5ms or less (resistive load) OFF→ON/0.5ms or less |
Operating Voltage Range (V) |
DC 10.2 to 26.4 (Ripple ratio within 5%) |
Surge Killer |
None |
Maximum Load Current (mA) |
Approx. 500/1 point (150/1 point when all points are ON) 4.8A/1 common |
Output Format |
Sink type |
Rated Load Voltage (V) |
DC12/24 |
Inrush current (A) |
1 / Maximum 10ms or less |
Leakage Current |
OFF / 0.1mA |
