| Model No | CTWL-15S2-9U |
| Type of Product | Assembly Terminal Block |
| Shape | 2nd grade |
| Monotaro ID | 7569497 |
Model No |
CTWL-15S2-9U |
Type of Product |
Assembly Terminal Block |
Shape |
2nd grade |
Monotaro ID |
7569497 |
No. of Pole |
9 Pole |
Country of Origin |
Japan |
Import Country |
Direct Import from Japan |
Type of Sign |
DIN35 mm |
Compatible Cable |
(JIS) 1.25/2/(TUV certified) AWG20-14 (stranded wire) |
Rated Insulation Voltage (V) |
AC DC660/(TU certified) AC DC600 |
Terminal Spacing |
8 mm |
Name of Manufacturer/Packer/Importer |
Toyo Giken Co., Ltd. |
Terminal Connection Type |
Self-Up |
Overall Length L |
Terminal block:81 mm |
Component Part |
(Intermediate plate) CTW-15S2, (Side plate) CTW-15L2 (AB set), (Cover) CA-30, (Name plate) M-1LE, (Rail) DAV4, (Fastener) HDV-2 |
Energized Current Rating |
1.25mm²-15A/2mm²-15A/(TUV certified) 15A |
Screw Dimension |
M3.5 |
