Ships within 25 days
View
View
View
View
| Model No | PTXL-225S-12P |
| Type of Product | Assembly Terminal Block |
| Screw Size | M10 |
| Shape | 1 Stage |
Model No |
PTXL-225S-12P |
Type of Product |
Assembly Terminal Block |
Screw Size |
M10 |
Shape |
1 Stage |
Monotaro ID |
13053105 |
Tightening Torque (Nm) |
10.0 to 14.7(JIS C8201-7-1), 18.0 to 23.0(JIS C2805) |
No. of Pole |
12 Pole |
Country of Origin |
Japan |
Import Country |
Direct Import from Japan |
Rated Insulation Voltage (V) |
AC/DC1000 |
Terminal Spacing |
35 mm |
Name of Manufacturer/Packer/Importer |
Toyo Giken Co., Ltd. |
Terminal Connection Type |
Self-Up |
Rated Carrying Current (A) |
60mm²：175 / 100mm²：240 |
Structure |
stud |
Type of Terminal Fitting |
DIN35mm |
