Ships within 19 days
View
View
View
View
| Model No | PTUL-80AG-5P |
| Type of Product | Assembly Terminal Block |
| Features | Oil and chemical resistant |
| Screw Size | M5 |
Model No |
PTUL-80AG-5P |
Type of Product |
Assembly Terminal Block |
Features |
Oil and chemical resistant |
Screw Size |
M5 |
Shape |
1 Stage |
Monotaro ID |
12301865 |
Tightening Torque (Nm) |
2.0 to 3.0 |
No. of Pole |
5 Pole |
Country of Origin |
Japan |
Import Country |
Direct Import from Japan |
Type of Sign |
DIN35 mm |
Compatible Cable |
5.5, 8, 14(JIS) |
Rated Insulation Voltage (V) |
AC・DC 600 |
Terminal Spacing |
14 mm |
Name of Manufacturer/Packer/Importer |
Toyo Giken Co., Ltd. |
Terminal Connection Type |
Screw Up |
Set Contents |
Terminal block |
Rated Carrying Current (A) |
5.5mm²：40, 8mm²：50, 14mm²：75 |
Overall Length L |
Terminal block:76 mm |
Mounting Pitch b (mm) |
110 |
Overall Length A (mm) |
Rail: 120 |
