| Model No | VTXL-2/3-96P |
| Color | Gray |
| Type of Product | Assembly Terminal Block |
| Shape | 1 Stage |
Model No |
VTXL-2/3-96P |
Color |
Gray |
Type of Product |
Assembly Terminal Block |
Shape |
1 Stage |
Monotaro ID |
62722199 |
No. of Pole |
96 Pole |
Country of Origin |
Japan |
Import Country |
Direct Import from Japan |
Type of Sign |
DIN35 mm |
Compatible Cable |
(JIS)0.5/0.75/1.25/1.5/2 |
Applicable crimp terminal |
DIN46228-4 compliant |
Rated Insulation Voltage (V) |
(General specifications) AC/DC 500, (UL certified specifications) AC/DC 300, (CUL certified specifications) AC/DC 300, (TUV certified specifications) AC/DC 500 |
Terminal Spacing |
4.2 mm |
Name of Manufacturer/Packer/Importer |
Toyo Giken Co., Ltd. |
Terminal Connection Type |
Spring Lock |
Rated Carrying Current (A) |
(General specifications) 6/9/13/17/24, (UL certified specifications) 20, (CUL certified specifications) 20, (TUV certified specifications) 24 |
Applicable Wire Size |
(UL certified) AWG26-12, (CUL certified) AWG26-12, (TUV certified) AWG26-14 |
Wire Stripping Length |
10 to 11 mm |
