| Model No | ITL-3001-2P |
| Type of Product | Assembly Terminal Block |
| Monotaro ID | 8680257 |
| Tightening Torque (Nm) | (Primary Side) 10.0 to 14.7, 6.0 to 9.0, (Secondary Side) 6.0 to 9.0, 2.5 to 3.7 |
Model No |
ITL-3001-2P |
Type of Product |
Assembly Terminal Block |
Monotaro ID |
8680257 |
Tightening Torque (Nm) |
(Primary Side) 10.0 to 14.7, 6.0 to 9.0, (Secondary Side) 6.0 to 9.0, 2.5 to 3.7 |
No. of Pole |
2 Pole |
Terminal Screw |
(Primary side) M10 x 20L, M8 x 16L, (Secondary side) M8 x 16L, M6 x 14L |
Country of Origin |
Japan |
Import Country |
Direct Import from Japan |
Rated Insulation Voltage (V) |
600 V AC/DC |
Name of Manufacturer/Packer/Importer |
Toyo Giken Co., Ltd. |
Connectable Wire (mm2) |
(Primary side) 150 x 1, 60 x 2, (Secondary side) 60 x 3, 22 x 2 |
Rated Carrying Current (A) |
300 A |
