Ships within 25 days
View
View
View
View
| Model No | VTXL-1.5/4-PE-156P |
| Type of Product | Assembly Terminal Block |
| Material | [Spring] SUS [Conductive Plate] Copper [Name Plate] PVC (White) |
| Insulation Resistance | 200 mΩ or more between each live part and between each live part and the mounting metal plate (DC 500V megger) |
Model No |
VTXL-1.5/4-PE-156P |
Type of Product |
Assembly Terminal Block |
Material |
[Spring] SUS [Conductive Plate] Copper [Name Plate] PVC (White) |
Insulation Resistance |
200 mΩ or more between each live part and between each live part and the mounting metal plate (DC 500V megger) |
Shape |
1 Stage |
Monotaro ID |
57553636 |
No. of Pole |
156 Pole |
Country of Origin |
Japan |
Import Country |
Direct Import from Japan |
Terminal Block |
VTX-1.5/4-PE |
Rated Insulation Voltage (V) |
500 V |
Name of Manufacturer/Packer/Importer |
Toyo Giken Co., Ltd. |
Terminal Connection Type |
Spring Lock |
Temperature Rise |
Temperature Rise of Conductive Metal Fittings: 35°C or Less |
Rated Impulse Withstand Voltage (kV) |
6 to 8 kV |
Conformed Standard |
JIS C 8201-7-1/NECA C 2811 (formerly JIS C 2811) |
Operation Environment |
Ambient temperature: -25°C to +60°C (no freezing or condensation), relative humidity: 45 to 85% |
Button Specifications |
66 nylon resin UL94 V-0 |
Insulator |
66 nylon resin UL94 V-0 |
Commercial Frequency Withstand Voltage (kV) |
3000/min |
