Ships within 25 days
View
View
View
View
| Model No | PTKC-300-3P |
| Type of Product | Assembly Terminal Block |
| Screw Size | M10 |
| Shape | 1 Stage |
Model No |
PTKC-300-3P |
Type of Product |
Assembly Terminal Block |
Screw Size |
M10 |
Shape |
1 Stage |
Monotaro ID |
9231060 |
Tightening Torque (Nm) |
10.0 to 14.7 |
No. of Pole |
3 Pole |
Country of Origin |
Japan |
Import Country |
Direct Import from Japan |
Type of Sign |
Direct Attachment |
Terminal Block |
Total length L 193mm |
Rated Insulation Voltage (V) |
AC/DC 1000/AC/DC 1000/AC/DC 1000 (UL certified) AC/DC 600 (CSA certified) AC/DC 600 (TU certified) AC/DC 660 |
Terminal Spacing |
47 mm |
Name of Manufacturer/Packer/Importer |
Toyo Giken Co., Ltd. |
Terminal Connection Type |
Self-Up |
Rated Carrying Current (A) |
175/240/310 (UL certified) 300 (CSA certified) 300 (TUV certified) 300 |
Structure |
Large current (200A~) |
Shaft Length (mm) |
155 |
Cable Size |
(JIS)60/100/150 (UL certified) AWG2/0 to 300 MCM stranded wire (CSA certified) AWG2/0 to 300 MCM stranded wire (TUV certified) AWG2 to 250 MCM stranded wire |
Component Part |
Intermediate plate: PT-300 / Side plate: PT-230KC / Cover: CTC-300, CTEP-300 / Name plate: AP-12 / Shaft: M6 shaft |
Mounting Screw Spacing (mm) |
B 178 |
