| Model No | C08XD-AT1N |
| Type of Product | Mixed Terminal Connector Type |
| Monotaro ID | 87056444 |
| Connection Type | External / 9-pole 2-piece connector (transmission path, unit power supply terminal, I / O power supply terminal, COM1, COM2) |
Model No |
C08XD-AT1N |
Type of Product |
Mixed Terminal Connector Type |
Monotaro ID |
87056444 |
Connection Type |
External / 9-pole 2-piece connector (transmission path, unit power supply terminal, I / O power supply terminal, COM1, COM2) |
Country of Origin |
Japan |
Import Country |
Direct Import from Japan |
Common Specifications |
16 points per common |
Type of Sign |
DIN Rail |
Name of Manufacturer/Packer/Importer |
Toyo Giken Co., Ltd. |
Mass (g) |
About 145 |
Insulation Type |
Photocoupler insulation |
Withstand voltage (V / min) |
[Between DC external terminals and ground] AC500 |
Terminal Connection Type |
e-CON |
Number of Input Points |
8 |
No. Of Output |
8 |
Rated Input Current |
About 5 mA |
Input format |
Sink type |
Response Time |
[Input] 0.2ms or less (at 24VDC) [Output] ON→OFF/1.5ms or less (resistive load), OFF→ON/0.5ms or less |
Operating Voltage Range (V) |
DC 19.2 to 26.4 (Ripple rate within 5%) |
Surge Killer |
None |
Maximum Load Current (mA) |
[Output section] Approx. 500/1 point 2.4A / common (300/1 point when all points are ON) |
Output Format |
Sink type |
Rated Load Voltage (V) |
DC24 |
Inrush current (A) |
[Output unit] 1 / Maximum 10 ms or less |
Leakage Current |
[Output] OFF / 0.1mA |
Input Resistance |
About 4.7kΩ |
