| Model No | C32X-CT1E |
| Type of Product | CC Link Terminal |
| Connector | 3-wire pressure contact type connector |
| Monotaro ID | 87060714 |
Model No |
C32X-CT1E |
Type of Product |
CC Link Terminal |
Connector |
3-wire pressure contact type connector |
Monotaro ID |
87060714 |
Connection Type |
External / 7-pole 2-piece connector (transmission path, unit power supply terminal, FG terminal) |
Country of Origin |
Japan |
Import Country |
Direct Import from Japan |
Common Specifications |
32 points per common |
Type of Sign |
DIN Rail |
Name of Manufacturer/Packer/Importer |
Toyo Giken Co., Ltd. |
Mass (g) |
About 205 |
Insulation Type |
Photocoupler insulation |
Terminal Connection Type |
e-CON |
Number of Input Points |
32 |
Rated Input Current |
About 5 mA |
Rated Input Voltage (V) |
DC24 |
Input format |
Sink and source shared type |
Response Time |
0.2 ms or less (at 24 VDC) |
Operating Voltage Range (V) |
DC 19.2 to 26.4 (Ripple rate within 5%) |
Input Resistance |
About 4.7kΩ |
