| Model No | CTWL-15R-106U |
| Type of Product | Assembly Terminal Block |
| Shape | 2nd grade |
| Monotaro ID | 7565148 |
Model No |
CTWL-15R-106U |
Type of Product |
Assembly Terminal Block |
Shape |
2nd grade |
Monotaro ID |
7565148 |
No. of Pole |
106 Pole |
Country of Origin |
Japan |
Import Country |
Direct Import from Japan |
Type of Sign |
DIN35 mm |
Compatible Cable |
Screw side 2/wrapping side Φ0.8×2 |
Rated Insulation Voltage (V) |
AC・DC 250 |
Terminal Spacing |
8 mm |
Name of Manufacturer/Packer/Importer |
Toyo Giken Co., Ltd. |
Terminal Connection Type |
Self-Up |
Structure |
wrapping |
Overall Length L |
Terminal block:857 mm |
Component Part |
(Intermediate plate) CTW-15R, (Side plate) CTW-15L (AB set), (Cover) CA-30, (Name plate) M-1LE, (Rail) DAV4, (Fastener) HDV-2 |
Energized Current Rating |
Screw side 2mm²-15A / Wrapping side Φ0.8×2-15A |
Screw Dimension |
M3.5 |
