| Model No | VTXL-1.5/4-248P |
| Type of Product | Assembly Terminal Block |
| Shape | 1 Stage |
| Monotaro ID | 57557310 |
Model No |
VTXL-1.5/4-248P |
Type of Product |
Assembly Terminal Block |
Shape |
1 Stage |
Monotaro ID |
57557310 |
No. of Pole |
248 Pole |
Country of Origin |
Japan |
Import Country |
Direct Import from Japan |
Applicable crimp terminal |
DIN46228-4 compliant |
Rated Insulation Voltage (V) |
AC・DC 500 |
Terminal Spacing |
3.5 mm |
Name of Manufacturer/Packer/Importer |
Toyo Giken Co., Ltd. |
Terminal Connection Type |
Spring Lock |
Energized Current Rating |
Wire sizes (JIS): 0.5mm² 6A , 0.75mm² 9A , 1.25mm² 17A , 1.5mm² 17A |
Type of Terminal Fitting |
DIN35mm |
Wire Stripping Length |
10 to 11 mm |
Various Certifications |
UL certified: AWG28-16 AC/DC 300V 10A, TUV certified: AWG28-16 AC/DC 500V 17A |
