Ships within 25 days
View
View
View
View
| Model No | PCV5-1J502 |
| Type of Product | Spring Lock Type Connector Terminal Block (PCV5 Series) |
| Connector | Japan Aviation Electronics Industry, Ltd./PS-50PE-D4T1-LP1 |
| Dimensions A (mm) | 132 |
Model No |
PCV5-1J502 |
Type of Product |
Spring Lock Type Connector Terminal Block (PCV5 Series) |
Connector |
Japan Aviation Electronics Industry, Ltd./PS-50PE-D4T1-LP1 |
Dimensions A (mm) |
132 |
Monotaro ID |
87052253 |
No. of Pole |
50 Pole |
Dimensions B (mm) |
108 |
Country of Origin |
Japan |
Import Country |
Direct Import from Japan |
Type of Sign |
DIN Rail |
Rated Insulation Voltage (V) |
125 V AC/DC |
Terminal Spacing |
5 mm |
Name of Manufacturer/Packer/Importer |
Toyo Giken Co., Ltd. |
Operation Ambient Temperature (°C) |
-15 to +60°C (no freezing or freezing) |
Withstand voltage (V / min) |
AC600 |
Terminal Connection Type |
Screwless / MIL |
Insulation_Resistance (MΩ) |
100 or more (at 500 VDC) |
Current Rating, IEC (A) |
1 |
Current Rating, JIS (A) |
1 |
Suitable Sockets |
Japan Aviation Electronics Industry, Ltd./PS-50SEN-D4P1-1D |
Strain Relief |
PS-SRN-50 |
