| Model No | PCV5-1T402 |
| Type of Product | Spring Lock Type Connector Terminal Block (PCV5 Series) |
| Connector | OMRON / XG4A-4031 |
| RoHS Directive | Correspondence |
Model No |
PCV5-1T402 |
Type of Product |
Spring Lock Type Connector Terminal Block (PCV5 Series) |
Connector |
OMRON / XG4A-4031 |
RoHS Directive |
Correspondence |
Dimensions A (mm) |
107 |
Monotaro ID |
87052271 |
No. of Pole |
40 Pole |
Dimensions B (mm) |
90 |
Country of Origin |
Japan |
Import Country |
Direct Import from Japan |
Type of Sign |
DIN Rail |
Rated Insulation Voltage (V) |
125 V AC/DC |
Terminal Spacing |
5 mm |
Name of Manufacturer/Packer/Importer |
Toyo Giken Co., Ltd. |
Operation Ambient Temperature (°C) |
-15 to +60°C (no freezing or freezing) |
Withstand voltage (V / min) |
AC600 |
Terminal Connection Type |
Screwless / MIL |
Insulation_Resistance (MΩ) |
100 or more (at 500 VDC) |
Current Rating, IEC (A) |
1 |
Current Rating, UL (A) |
1 |
Current Rating, JIS (A) |
1 |
Suitable Sockets |
OMRON Corporation / XG4M-2040 |
Strain Relief |
XG4T-4004 |
