| Model No | JTL-10-4P |
| Type of Product | Assembly Terminal Block |
| Screw Size | M3 |
| Rail | mm |
Model No |
JTL-10-4P |
Type of Product |
Assembly Terminal Block |
Screw Size |
M3 |
Rail |
mm |
Shape |
1 Stage |
Monotaro ID |
9231419 |
Tightening Torque (Nm) |
0.5 to 1.2 |
No. of Pole |
4 Pole |
Country of Origin |
Japan |
Import Country |
Direct Import from Japan |
Type of Sign |
DIN35 mm |
Terminal Block |
Total length L 36mm |
Rated Insulation Voltage (V) |
AC・DC 800 |
Terminal Spacing |
7 mm |
Name of Manufacturer/Packer/Importer |
Toyo Giken Co., Ltd. |
Terminal Connection Type |
Screw Up |
Rated Carrying Current (A) |
16 |
Cable Size |
(JIS)1.25 |
Component Part |
Intermediate plate: JT-10 / Side plate: JT-120L / Cover: CA-40 / Name plate: AM-10 / Rail: DAV4 / Fastener: GTY18 |
Mounting Screw Spacing (mm) |
B 70 |
