| Model No | PCN-1T20 |
| Type of Product | Connector Terminal Block (PCN Series) |
| Connector | OMRON / XG4A-2031 |
| RoHS Directive | Correspondence |
Model No |
PCN-1T20 |
Type of Product |
Connector Terminal Block (PCN Series) |
Connector |
OMRON / XG4A-2031 |
RoHS Directive |
Correspondence |
Dimensions A (mm) |
86 |
Monotaro ID |
87058596 |
Tightening Torque (Nm) |
1.2 |
No. of Pole |
20 Pole |
Terminal Screw |
M3×9.5 |
Dimensions B (mm) |
65 |
Country of Origin |
Japan |
Import Country |
Direct Import from Japan |
Type of Sign |
DIN Rail / Direct Mounting |
Compatible Cable |
Up to 1.25 |
Rated Insulation Voltage (V) |
125 V AC/DC |
Terminal Spacing |
7.62 mm |
Name of Manufacturer/Packer/Importer |
Toyo Giken Co., Ltd. |
Operation Ambient Temperature (°C) |
-15 to +60°C |
Withstand voltage (V / min) |
AC600 |
Terminal Connection Type |
Screw / Flat |
Insulation_Resistance (MΩ) |
100 or more (with DC500V mega) |
Current Rating, IEC (A) |
1 |
Current Rating, UL (A) |
1 |
Current Rating, JIS (A) |
1 |
Suitable Sockets |
XG4M-2030 |
Strain Relief |
Set in socket |
