| Type | Inductance Type |
| Country of Origin | India |
| Repeatability | 0.15 µm |
| Type of Product | Probe |
Type |
Inductance Type |
Country of Origin |
India |
Repeatability |
0.15 µm |
Type of Product |
Probe |
Weight |
16 g |
Range |
±0.9 mm |
Accuracy |
± (0.3+3x|L|3) µm |
Cable Length |
2 m |
Model No |
9420-AP02 |
Sensor Type |
LVDT (Full Bridge) |
Stroke |
Mechanical: 2.2 mm |
Measuring Force |
0.75 N |
Name of Manufacturer/Packer/Importer |
Insize |
Contact Type |
Carbide |
Storage Environment |
Temperature: -20°C-100°C, Humidity: =<80% (Non Condensing) |
Interface |
5 Wire Aviation Interface |
Drift |
Thermal: 0.25 µm/°C |
Operating Environment |
Temperature: -10°C-60°C, Humidity: =<80% (Non Condensing) |
Thread |
Insert: M2.5 |
Cover Type |
Fluorinated Elastomer |
