| Thermal sensitivity (NETD) | 50 mK |
| Frame Rate | 25 Hz |
| Temperature Accuracy | ± 2% of rdg or ± 2 °C, whichever is greater (@ 25 °C ± 5 °C ambient temperature) |
| Operating Humidity | 10% to 90% RH, non-condensing |
Thermal sensitivity (NETD) |
50 mK |
Frame Rate |
25 Hz |
Temperature Accuracy |
± 2% of rdg or ± 2 °C, whichever is greater (@ 25 °C ± 5 °C ambient temperature) |
Operating Humidity |
10% to 90% RH, non-condensing |
Temperature Range |
-10 °C to 150 °C, 100°C to 550 °C |
Operating Temperature |
0 °C to 40 °C |
Storage Temperature |
-30 °C to 60 °C |
Type of Product |
Mobile Thermal Camera |
Weight |
22 g |
Dimension |
59 x 32 x 10 mm |
IR Resolution |
256 x 192 |
Model No |
TC01A |
Spatial Resolution |
3.81 mrad |
Country of Origin |
India |
Name of Manufacturer/Packer/Importer |
INSTRUKART HOLDING |
Focal Length (Mm) |
Fixed focal length: 3.2 mm |
Pixel Size |
12 µm |
Field of View |
56° x 42° |
Warm-up Time (min) |
1 minute |
USB Interface |
Type-C |
Drop Test |
1 m |
Power Consumption |
350 mW (Typical) |
Storage Altitude |
12000 m |
Measurement Distance |
Temp 0.25 m to 5 m |
Shutter |
Mode Built-in automatic shutter |
Operating Altitude |
2000 m |
Spectral Range |
8 to 14 µm |
