| Type of Product | Thermostat |
| Model No | PTSC-090S |
| Country of Origin | Japan |
| Control | ON/OFF control |
Type of Product |
Thermostat |
Model No |
PTSC-090S |
Country of Origin |
Japan |
Control |
ON/OFF control |
Name of Manufacturer/Packer/Importer |
Shinohara Electric Co., Ltd. |
Differential |
4℃ |
Monotaro ID |
11074567 |
Import Country |
Direct Import from Japan |
Mass (g) |
140 |
Insulation Resistance (MOhm) |
100 or more at 500 VDC |
Heat Resistance |
Main unit: 105 ℃ |
Thread Size |
Terminal: M3.5 |
Temperature Display |
OFF temperature |
Withstand Voltage |
Between terminals: 1500 V / min |
RoHS Directive |
Correspondence |
Temperature Difference Max |
4 |
Setting Temperature (℃) |
0 to 90 |
Contact |
Capacity: 20A / 250V AC (resistive load), 6A / 250V AC (inductive load) |
