Ships within 90 days
Nameplate RPM
Power
View
View
View
View
| Mounting Type | Rigid Base |
| Rated Voltage | 230/460V AC |
| Phase | Three |
| Type of Product | General Purpose Motor |
Mounting Type |
Rigid Base |
Rated Voltage |
230/460V AC |
Phase |
Three |
Type of Product |
General Purpose Motor |
Pole |
- |
Power |
2 HP |
Standard |
CE CSA UL |
Frame |
56H |
Class |
F |
Item Code |
31LH34 |
Frame Material |
Rolled Steel |
Country of Origin |
Mexico |
Duty Cycle |
Continuous |
Shaft Diameter |
5/8 inch |
Thermal Protection |
None |
Enclosure Design |
Open Dripproof |
Overall Length |
12-11/16 inch |
Shaft rotation |
CW/CCW |
Inverter Rated Watts |
Yes |
UNSPSC Code |
26101612 |
Length Less Shaft |
9-11/16 inch |
Shaft Length |
1-7/8 inch |
Full Load (Amps) |
5.3/2.7 A |
Includes |
MIMI 8S470AShaft Key |
Max. Ambient Temp. (F) |
104 °F |
Part No |
31LH34 |
No. Of Speeds |
1 |
Motor Design |
3-Phase |
Motor Shaft Design |
Keyed |
Motor Mounting Position |
Horizontal |
Nominal Efficiency |
85.5 % |
RPM Range |
3,001-3,600 |
Motor Service Factor |
1.15 |
Motor Bearings |
Ball |
Motor Application |
General Application |
CC Number |
CC029A |
Hz |
60/50 Hz |
Manufacturer Part Number |
31LH34 |
Nameplate Speed |
1,730 RPM |
Nameplate RPM |
1730 RPM |
Length (mm) |
246.1 mm |
Overall Length (cm) |
32.23 cm |
Shaft Diameter (mm) |
15.87 mm |
Shaft Length (mm) |
47.63 mm |
