| Outer Diameter | 37 mm |
| Material | High Carbon Chromium Steel |
| Type of Product | Needle Bearing With Thrust Roller Bearing NBX |
| Model No | NBX2530 |
Outer Diameter |
37 mm |
Material |
High Carbon Chromium Steel |
Type of Product |
Needle Bearing With Thrust Roller Bearing NBX |
Model No |
NBX2530 |
Type |
Without inner ring |
Country of Origin |
Japan |
Mass (g) |
143 |
Race ring shape |
Needle roller bearing |
Rolling element material |
High carbon chromium bearing steel |
JIS grade |
0 |
Monotaro ID |
38313186 |
Dimension d1 (Φmm) |
42 |
Inscribed Circle Diameter Fw (Φmm) |
25 |
Import Country |
Direct Import from Japan |
Name of Manufacturer/Packer/Importer |
Nippon Thompson Co., Ltd. |
Basic Dynamic Load Rating (N) |
(Radial) 20000 (Axial) 22700 |
Cover |
Without dust cover |
Basic Static Load Rating (N) |
(Radial) 32100 (Axial) 60700 |
Allowable Rotation Speed (min-1 [rpm]) |
9000 |
Dimension L (mm) |
30 |
Dimensions H (mm) |
11 |
