| Inner Diameter | 14 mm |
| Outer Diameter | 26 mm |
| Material | High Carbon Chromium Steel |
| Type of Product | Needle Bearing With Thrust Roller Bearing NBXI |
Inner Diameter |
14 mm |
Outer Diameter |
26 mm |
Material |
High Carbon Chromium Steel |
Type of Product |
Needle Bearing With Thrust Roller Bearing NBXI |
Model No |
NBXI1425Z |
Type |
With inner ring |
Country of Origin |
Japan |
Mass (g) |
72.5 |
Race ring shape |
Needle roller bearing |
Rolling element material |
High carbon chromium bearing steel |
JIS grade |
0 |
Monotaro ID |
38313457 |
Inscribed Circle Diameter Fw (Φmm) |
17 |
Import Country |
Direct Import from Japan |
Name of Manufacturer/Packer/Importer |
Nippon Thompson Co., Ltd. |
Width B (mm) |
17 |
Basic Dynamic Load Rating (N) |
(Radial) 12900 (Axial) 11400 |
Cover |
With dust cover |
Basic Static Load Rating (N) |
(Radial) 16300 (Axial) 28600 |
Allowable Rotation Speed (min-1 [rpm]) |
13000 |
Dimension L (mm) |
25 |
Dimensions H (mm) |
9 |
Dimension d2 (Φmm) |
31 |
Inner ring |
LRT141717 |
