| Inner Diameter | 35 mm |
| Outer Diameter | 52 mm |
| Material | High Carbon Chromium Steel |
| Type of Product | Needle Bearing With Thrust Roller Bearing NBXI |
Inner Diameter |
35 mm |
Outer Diameter |
52 mm |
Material |
High Carbon Chromium Steel |
Type of Product |
Needle Bearing With Thrust Roller Bearing NBXI |
Model No |
NBXI3532Z |
Type |
With inner ring |
Country of Origin |
Japan |
Mass (g) |
294 |
Race ring shape |
Needle roller bearing |
Rolling element material |
High carbon chromium bearing steel |
JIS grade |
0 |
Monotaro ID |
38313502 |
Inscribed Circle Diameter Fw (Φmm) |
40 |
Import Country |
Direct Import from Japan |
Name of Manufacturer/Packer/Importer |
Nippon Thompson Co., Ltd. |
Width B (mm) |
20 |
Basic Dynamic Load Rating (N) |
(Radial) 29400 (Axial) 24700 |
Cover |
With dust cover |
Basic Static Load Rating (N) |
(Radial) 54100 (Axial) 133000 |
Allowable Rotation Speed (min-1 [rpm]) |
6000 |
Dimension L (mm) |
32 |
Dimensions H (mm) |
13 |
Dimension d2 (Φmm) |
61 |
Inner ring |
LRT354020 |
