| Inner Diameter | 45 mm |
| Outer Diameter | 85 mm |
| Material | High Carbon Chromium Steel |
| Type of Product | Single Thrust Ball Bearing 5353 Type (Aligning Seat Type) |
Inner Diameter |
45 mm |
Outer Diameter |
85 mm |
Material |
High Carbon Chromium Steel |
Type of Product |
Single Thrust Ball Bearing 5353 Type (Aligning Seat Type) |
Model No |
53309U |
Country of Origin |
Japan |
Mass (g) |
888 |
Width T (mm) |
28 |
Mounting Dimension, Maximum ra (mm) |
1 |
Monotaro ID |
38398236 |
Dimension d1 (Φmm) |
47 |
Mounting Dimension, Maximum Da (Φmm) |
61 |
Import Country |
Direct Import from Japan |
Name of Manufacturer/Packer/Importer |
NSK Ltd. |
Allowable Speed (min-1[r.p.m]) Grease Lubrication |
2000 |
Nominal No. |
53309U |
Dimension d3 (mm) |
90 |
Dimension R |
(Minimum) 1 mm |
Mounting Dimension, Maximum da (mm) |
69 |
Dimension T4 (mm) |
33 |
Dimension T3 (mm) |
30.1 |
Dimension d2 (Φmm) |
65 |
Dimensions B (mm) |
10 |
Dimensions A (mm) |
25 |
