| Inner Diameter | 35 mm |
| Outer Diameter | 68 mm |
| Material | High Carbon Chromium Steel |
| Type of Product | Single Thrust Ball Bearing 5353 Type (Aligning Seat Type) |
Inner Diameter |
35 mm |
Outer Diameter |
68 mm |
Material |
High Carbon Chromium Steel |
Type of Product |
Single Thrust Ball Bearing 5353 Type (Aligning Seat Type) |
Model No |
53307U |
Country of Origin |
Japan |
Mass (g) |
488 |
Width T (mm) |
24 |
Mounting Dimension, Maximum ra (mm) |
1 |
Monotaro ID |
38398211 |
Dimension d1 (Φmm) |
37 |
Mounting Dimension, Maximum Da (Φmm) |
48 |
Import Country |
Direct Import from Japan |
Name of Manufacturer/Packer/Importer |
NSK Ltd. |
Allowable Speed (min-1[r.p.m]) Grease Lubrication |
2400 |
Nominal No. |
53307U |
Dimension d3 (mm) |
72 |
Dimension R |
(Minimum) 1 mm |
Mounting Dimension, Maximum da (mm) |
55 |
Dimension T4 (mm) |
28 |
Dimension T3 (mm) |
25.6 |
Dimension d2 (Φmm) |
52 |
Dimensions B (mm) |
7.5 |
Dimensions A (mm) |
24 |
