Ships within 19 days
Outer Diameter
Model No
View
View
View
View
| Inner Diameter | 60 mm |
| Width | 35 mm |
| Outer Diameter | 110 mm |
| Type of Product | Thrust Ball Bearing |
Inner Diameter |
60 mm |
Width |
35 mm |
Outer Diameter |
110 mm |
Type of Product |
Thrust Ball Bearing |
Model No |
51312 |
Country of Origin |
Japan |
Load direction |
radial |
Chamfering Size r (mm) |
1.1 (minimum) |
Outer ring type |
flat |
No. of Track Trains |
Single row |
Shield Shape |
Open type |
Race ring shape |
Thrust ball bearing |
Body Material |
High carbon chromium bearing steel |
Rolling element material |
High carbon chromium bearing steel |
JIS grade |
0 |
Basic dynamic load rating Ca (N) |
123000 |
Basic static load rating Coa (N) |
267000 |
Monotaro ID |
347462 |
Dimension d1 (Φmm) |
110 (max) |
Grease Limiting Speed (RPM) |
1600 |
Oil Limiting Speed (RPM) |
2300 |
Reference mass (g) |
1370 |
Import Country |
Direct Import from Japan |
Name of Manufacturer/Packer/Importer |
NTN Corp. |
