| Inner Diameter | 90 mm |
| Outer Diameter | 120 mm |
| Material | High Carbon Chromium Steel |
| Type of Product | Single Thrust Ball Bearings 51100 Series |
Inner Diameter |
90 mm |
Outer Diameter |
120 mm |
Material |
High Carbon Chromium Steel |
Type of Product |
Single Thrust Ball Bearings 51100 Series |
Model No |
51118YP5 |
Country of Origin |
Japan |
Load direction |
Radial |
Width T (mm) |
22 |
Outer ring type |
Flat |
No. of Track Trains |
Single row |
Shield Shape |
Open type |
Race ring shape |
Thrust ball bearing |
Rolling element material |
High carbon chromium bearing steel |
JIS grade |
5 |
Basic dynamic load rating Ca (N) |
59500 |
Basic static load rating Coa (N) |
190000 |
Monotaro ID |
8837875 |
Dimension d1 (Φmm) |
92 (minimum) |
Reference mass (g) |
687 |
Import Country |
Direct Import from Japan |
Name of Manufacturer/Packer/Importer |
NTN Corporation |
Chamfer Dimension r (mm) |
1 (minimum) |
Permissible Speed (min-1) Oil Lubrication |
2700 |
Permissible Speed (min-1) Grease Lubrication |
1900 |
