| Type of Product | Thyristor |
| Model No | TYN825RG |
| Dimension | 10.4x4.6x15.9 mm |
| Country of Origin | USA |
Type of Product |
Thyristor |
Model No |
TYN825RG |
Dimension |
10.4x4.6x15.9 mm |
Country of Origin |
USA |
Name of Manufacturer/Packer/Importer |
RS Components & Controls (I) Ltd |
Maximum Holding Current |
50 mA |
Repetitive Peak Off-State Current |
5 µA |
Rated Average On-State Current |
16 A |
Thyristor Type |
SCR |
Repetitive Peak Reverse Voltage |
800 V |
Repetitive Peak Forward Blocking Voltage |
800 V |
Maximum Gate Trigger Voltage |
1.3 V |
Surge Current Rating |
314 A |
Maximum Operating Temperature |
+125°C |
Maximum Gate Trigger Current |
40 µA |
Package Type |
TO-220AB |
Mounting Type |
Through Hole |
Pin Count |
3 |
Pack of |
5 Pcs |
Minimum Operating Temperature |
-40°C |
