| Type of Product | Timer Relay |
| Time Range | 0.1 s to 9999h |
| Width | 60.8 mm |
| Depth | 88.8 mm |
Type of Product |
Timer Relay |
Time Range |
0.1 s to 9999h |
Width |
60.8 mm |
Depth |
88.8 mm |
Terminal Type |
Screw |
Length |
35 mm |
Mounting Type |
DIN Rail |
Country of Origin |
Italy |
Series |
84 Series |
No. of Contacts |
2 |
Supply Voltage |
110 to 240 V AC/DC |
Maximum Current |
16 A |
Switch Configuration |
DPDT-2CO |
Operation Mode |
Multi Function (NFC Programmable) |
Minimum Voltage |
110 V AC/DC |
Maximum Operating Temperature |
+50°C |
Contact Configuration |
DPDT |
Maximum Voltage |
240 V AC/DC |
Minimum Operating Temperature |
-20°C |
Power Supply |
External |
Manufacturer Part Number |
84.02.0.230.0000 |
Name of Manufacturer/Packer/Importer |
RS Components & Controls (I) Ltd |
Number of Timer Functions |
Multi Function |
Time Increment |
Hours, Minutes, Seconds |
