| Model No | UTR-35 |
| Type of Product | Universal Timer Relay |
| Time Range | Sec (9.99/99.9/999), Min (9.59/99.9/999), Hour (9.59/99.9/999) |
| Mounting Type | DIN Rail Mount |
Warranty as per brand
100% Original Products
Secure payments
100% Buyer protection
Top Brands
Model No |
UTR-35 |
Type of Product |
Universal Timer Relay |
Time Range |
Sec (9.99/99.9/999), Min (9.59/99.9/999), Hour (9.59/99.9/999) |
Mounting Type |
DIN Rail Mount |
Size |
90x35x62 mm (HxWxD) |
Country of Origin |
India |
Relative Humidity |
Upto 95% RH Non-Condensing |
Frequency |
50-60 Hz |
Supply Voltage |
100-270 V AC |
Operating Temperature |
0°C-55°C |
Relay Type |
1 Relay 1 C/O |
Color |
White |
Name of Manufacturer/Packer/Importer |
Dhruv Enterprise |
Reset |
Front Panel Reset/Terminal Reset |
Counting Direction |
UP/DOWN |
Display Size |
UPPER: 1.01 cm (0.4 inch) & LOWER: 7.11 mm (0.28 inch) |
Relay Rating |
5 A, 230 V AC |
Power Consumption (VA) |
4 VA @230 V AC (Max) |
Display |
Upper: 3 Digit, 7 Segment | Lower: 3 Digit 7 Segment |
