| Operating Temperature Range | -20 to +80,℃ 60% RH or less (with no icing or condensation) |
| Monotaro ID | 46502757 |
| Type of Product | Ultra-Miniature Toggle Switch |
| Model No | A9TS12-0011 |
Warranty as per brand
100% Original Products
Secure payments
100% Buyer protection
Top Brands
Operating Temperature Range |
-20 to +80,℃ 60% RH or less (with no icing or condensation) |
Monotaro ID |
46502757 |
Type of Product |
Ultra-Miniature Toggle Switch |
Model No |
A9TS12-0011 |
Type |
Switch type |
Rating |
(Resistance load) AC / DC 28V + 14mA, AC / DC 20mV + 0.1μA (minimum current) |
Country of Origin |
Japan |
Terminal Type |
Printed circuit board terminal |
Import Country |
Direct Import from Japan |
Pack of |
1 Pcs |
Name of Manufacturer/Packer/Importer |
Omron Corporation |
Mass (g) |
0.3 |
Vibration |
Malfunction: 10 to 55Hz, double amplitude 1.5 mm |
Functional Operation |
ON・OFF・ON |
Contact Resistance (ohm) |
80 or less (initial value) |
Durability |
Mechanical / 50,000 or more, Electrical / 50,000 or more |
Insulation Resistance (MOhm) |
500 mohm or more (with DC500 V insulation resistance tester) |
Circuits |
Single pole double throw |
Withstand Voltage |
Between terminals and terminal ground 500 VAC for 1 min |
Ambient Humidity to Use |
45 to 85% RH (at +5 to 35 ° C) |
Operating Force (N) |
4.9 or less |
Part No |
64-3340-77 |
Shock Resistance (Malfunction) |
500 m/s² |
