| Model No | AP4000N2 |
| Type of Product | Fully Automatic Air Torque Body |
| Country of Origin | Japan |
| Accuracy (%) | ±5 |
Model No |
AP4000N2 |
Type of Product |
Fully Automatic Air Torque Body |
Country of Origin |
Japan |
Accuracy (%) |
±5 |
Hose Inner Diameter |
Φ12 mm |
Name of Manufacturer/Packer/Importer |
Tohnichi Manufacturing Co., Ltd. |
Square Drive (mm) |
a：38.1, b：42 |
Suitable Screw |
Normal steel: M48, high tension: M36 (M39) |
Load direction |
Right |
Overall Length (mm) |
541 |
Monotaro ID |
49701269 |
RoHS Directive |
Correspondence |
Included Components |
W5 Hexagon stick spanner |
Mass (Kg) |
About 22 |
Import Country |
Direct Import from Japan |
Specification Class |
Air tightening flow rate: 1.7 m³ |
Air Inlet |
R (PT) 3/8 |
Noise Level (dB (A)) (50/60Hz) |
80 |
Torque Adjustment Per 1 Scale (Nm) |
100 |
Rotation Speed at No Load (min-1 rpm) |
12 |
Overall Width (mm) |
411 |
Overall Height (mm) |
196 |
Adjustment Range |
2000 to 4000 Nm |
