| Model No | AP1200N2 |
| Type of Product | Fully Automatic Air Torque Body |
| Country of Origin | Japan |
| Accuracy (%) | ±5 |
Model No |
AP1200N2 |
Type of Product |
Fully Automatic Air Torque Body |
Country of Origin |
Japan |
Accuracy (%) |
±5 |
Hose Inner Diameter |
Φ12 mm |
Name of Manufacturer/Packer/Importer |
Tohnichi Manufacturing Co., Ltd. |
Square Drive (mm) |
a：25.4, b：26.5 |
Suitable Screw |
Normal steel: M30 (M33), High tension: M24 |
Load direction |
Right |
Overall Length (mm) |
375.5 |
Monotaro ID |
49701253 |
RoHS Directive |
Correspondence |
Included Components |
W5 Hexagon wrench, Sasae handle |
Mass (Kg) |
About 8.1 |
Import Country |
Direct Import from Japan |
Specification Class |
Air tightening flow rate: 0.46 m³ |
Air Inlet |
R (PT) 3/8 |
Noise Level (dB (A)) (50/60Hz) |
80 |
Torque Adjustment Per 1 Scale (Nm) |
50 |
Rotation Speed at No Load (min-1 rpm) |
46 |
Overall Width (mm) |
197.5 |
Overall Height (mm) |
269 |
Adjustment Range |
600 to 1200 Nm |
