| Type of Product | V Belt D Type |
| Model No | D190 |
| Country of Origin | INDONESIA |
| Length | 4826 mm |
Type of Product |
V Belt D Type |
Model No |
D190 |
Country of Origin |
INDONESIA |
Length |
4826 mm |
Effective Pitch Length (inch) |
190 Inch |
Belt shape |
D |
Type |
Standard |
Belt Height (mm) |
19.5 mm |
Minimum Pulley diameter (mm) |
355 mm |
Monotaro ID |
9245241 |
Maximum Speed |
30 m/sec |
Operating Temperature Range |
-40～+70 °C |
Resistance value (MΩ) |
50 MΩ or more |
Offset Angle |
40° |
Belt pitch circumference (mm) |
4826 mm |
Belt Top Width (mm) |
31.7 mm |
Belt Material |
Rubber |
Name of Manufacturer/Packer/Importer |
Mitsuboshi belting Ltd |
Import Country |
Direct Import from Japan |
