| Type of Product | Metal Oxide Varistor |
| Varistor Voltage | 56 V |
| Name of Manufacturer/Packer/Importer | Panasonic Corporation |
| Series | VF |
Warranty as per brand
100% Original Products
Secure payments
100% Buyer protection
Top Brands
Type of Product |
Metal Oxide Varistor |
Varistor Voltage |
56 V |
Name of Manufacturer/Packer/Importer |
Panasonic Corporation |
Series |
VF |
Country of Origin |
Japan |
Pack of |
5 Pcs |
Model No |
ERZVF2M560 |
Monotaro ID |
65236756 |
Maximum Rated Voltage |
AC: 35, DC: 45 V |
Current (A) (50/60Hz) |
Clamp: 2.5 |
Specifications |
PCQC (GB/T10193, GB/T10194). Metal Oxide Varistor ZNR Series SMD. Panasonic VF Surge Absorbers are designed for flow/reflow soldering. These surge absorbers feature low clamping voltage and high surge current capacity. VF Surge Absorbers belong to the zinc oxide nonlinear resistor (ZNR) series. They perform the same function as two back-to-back Zener diodes and one parallel-connected capacitor, while saving cost and board space. Compact size, surface mount, protective coating. Applications. Typical applications include absorbing switching surges in relays and switches, and protecting consumer and industrial equipment. They can be used to protect communication modules such as terminal adapters, modems, and xDSL. |
Material |
ZNR |
RoHS Directive |
Correspondence |
Lead Spacing |
2.5 mm |
Maximum Surge Current |
125 Amp |
Import Country |
Direct Import from Japan |
Voltage |
110 V |
Length (mm) |
8 |
Thickness (mm) |
3.2 |
