| Type of Product | Zero Phase Voltage Detector |
| Model No | VOC-1MS2 (VOC K3P CAP CABLE) |
| Country of Origin | JAPAN |
| Name of Manufacturer/Packer/Importer | Omron Corporation |
Type of Product |
Zero Phase Voltage Detector |
Model No |
VOC-1MS2 (VOC K3P CAP CABLE) |
Country of Origin |
JAPAN |
Name of Manufacturer/Packer/Importer |
Omron Corporation |
Import Country |
Direct Import from Japan |
Monotaro ID |
39100801 |
Mass (g) |
Approximately 550 (pieces) |
Set Contents |
Zero-phase voltage detection capacitor (VOC-1M), zero-phase voltage detection capacitor cap, zero-phase voltage converter (K3P-M), cable 1m |
Insulation Resistance (MOhm) |
1000 or more between high voltage terminal and mounting terminal (at DC1000V mega) |
Rated Frequency (Hz) |
50/60 |
Withstand Voltage |
Between high voltage terminal and mounting terminal: 22000 V AC for 1 min Between low voltage terminal and mounting terminal: 2000 V AC for 1 min |
Rated Voltage (V) |
AC 6600 |
Operation Environment |
Indoor (air) |
Insulation Class |
No. 6 A (JEC1201) |
Lightning Impulse Withstand Voltage |
1.2 / 50 μs wave Between high voltage terminal and mounting terminal: Peak value 65000V |
Rated Capacity |
250pF |
Compatible Models |
K2GS-H, K2GS-B, K2GV-C, K2ZC-K2GS-N, K2ZC-K2GV-NC |
Operation Ambient Temperature (°C) |
-20 to +60 |
