| Mounting Type | Surface Mount |
| Type of Product | Voltage Regulator |
| Output Voltage | 8 V |
| Dimension | 6.54 x 6.04 x 2.29mm |
Mounting Type |
Surface Mount |
Type of Product |
Voltage Regulator |
Output Voltage |
8 V |
Dimension |
6.54 x 6.04 x 2.29mm |
Pack of |
5 Pcs |
Country of Origin |
United Kingdom |
Name of Manufacturer/Packer/Importer |
Nisshinbo Micro Devices |
No. Of Output |
1 |
Regulator Type |
Linear Voltage |
Maximum Output Current |
500mA |
Package Type |
TO-252 |
Output Type |
Fixed |
Pin Count |
3 |
Maximum Input Voltage |
35 V |
Load Regulation |
80 mV |
Polarity |
Positive |
Height |
2.29mm |
Quiescent current |
4mA |
Length |
6.54mm |
Maximum Operating Temperature |
+85 °C |
Line Regulation |
60 mV |
Width |
6.04mm |
Minimum Operating Temperature |
-40 °C |
Power Rating |
1W |
Manufacturer Part Number |
NJM78M08DL1A-TE1 |
