Ships within 15 days
View
View
View
View
| Mounting Type | Surface Mount |
| Type of Product | Voltage Regulator |
| Output Voltage | 3.3 V |
| Dimension | 4.5 x 2.5 x 1.5mm |
Mounting Type |
Surface Mount |
Type of Product |
Voltage Regulator |
Output Voltage |
3.3 V |
Dimension |
4.5 x 2.5 x 1.5mm |
Pack of |
2000 Pcs |
Country of Origin |
United Kingdom |
Name of Manufacturer/Packer/Importer |
Nisshinbo Micro Devices |
No. Of Output |
1 |
Regulator Type |
Low Dropout Voltage |
Maximum Output Current |
180mA |
Package Type |
SOT-89 |
Output Type |
Fixed |
Pin Count |
6 |
Maximum Input Voltage |
20 V |
Load Regulation |
0.03 %/mA |
Polarity |
Positive |
Height |
1.5mm |
Quiescent current |
0.18mA |
Length |
4.5mm |
Maximum Operating Temperature |
+85 °C |
Line Regulation |
0.12 %/V |
Width |
2.5mm |
Minimum Operating Temperature |
-40 °C |
Accuracy |
3% |
Power Rating |
0.35W |
Manufacturer Part Number |
NJM2370U1-33 |
